Mud Pump Liners
Grizzly mud pump liners are designed and manufactured to meet or exceed original equipment specifications and API standards for all almost all types of mud pumps.
Features:
- Rated for drilling operating up to 5000 PSI.
- High chrome sleeve liners.
- Bore hardened to 62~69 Rockwell "C"
- “HP” lip design to prevent inner sleeve slipping.
- Extremely long service life.
|
PUMP MODEL
|
SIZE
|
PART NUMBER
|
|
LINER
|
LINER GASKET
|
|
8-P-80
|
4"
|
GM-0256-40HP
|
GM-1540140
|
|
4-1/2"
|
GM-0256-44HP
|
GM-1540142
|
|
5"
|
GM-0256-50HP
|
GM-1540144
|
|
5-1/2"
|
GM-0256-54HP
|
GM-1540146
|
|
6"
|
GM-0256-60HP
|
GM-1540148
|
|
6-1/4"
|
GM-0256-62HP
|
GM-1540149
|
|
9-P-100/10-P-130
|
4-1/2"
|
GM-0255-44HP
|
GM-1540142
|
|
5"
|
GM-0255-50HP
|
GM-1540120
|
|
5-1/2"
|
GM-0255-54HP
|
GM-1540122
|
|
5-3/4"
|
GM-0255-56HP
|
GM-1540123
|
|
6"
|
GM-0255-60HP
|
GM-1540124
|
|
6-1/4"
|
GM-0255-62HP
|
GM-1540150
|
|
6-1/2"
|
GM-0255-64HP
|
GM-1540126
|
|
6-3/4"
|
GM-0255-66HP
|
GM-1540126
|
|
F-350/500/650
|
3-1/2"
|
GM-0146-34HP
|
GM-7602-2200-34
|
|
4"
|
GM-0146-40HP
|
|
4-1/2"
|
GM-0146-44HP
|
|
5"
|
GM-0146-50HP
|
|
5-1/2"
|
GM-0146-54HP
|
|
6"
|
GM-0146-60HP
|
|
6-1/4"
|
GM-0146-62HP
|
|
6-1/2"
|
GM-0146-64HP
|
|
6-3/4"
|
GM-0146-66CR
|
|
BS F800/1000
F800/1000
|
4"
|
GM-0148-40HP
|
GM-7602-2200-32
|
|
4-1/2"
|
GM-0148-44HP
|
|
5"
|
GM-0148-50HP
|
|
5-1/2"
|
GM-0148-54HP
|
|
5-3/4“
|
GM-0148-56HP
|
|
6"
|
GM-0148-60HP
|
|
6-1/4"
|
GM-0148-62HP
|
|
6-1/2"
|
GM-0148-64HP
|
|
6-3/4"
|
GM-0148-66HP
|
|
7"
|
GM-0148-70CR
|
|
BS F-1300/1600
F-1300/1600
|
4"
|
GM-0145-40HP
|
GM-G800
|
|
4-1/2"
|
GM-0145-44HP
|
|
5"
|
GM-0145-50HP
|
|
5-1/2"
|
GM-0145-54HP
|
|
6"
|
GM-0145-60HP
|
|
6-1/2"
|
GM-0145-64HP
|
|
6-3/4"
|
GM-0145-66HP
|
|
7"
|
GM-0145-70HP
|
|
7-1/4"
|
GM-0145-72HP
|
|
7-1/2"
|
GM-0145-74HP
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PUMP MODEL
|
SIZE
|
PART NUMBER
|
|
LINER
|
LINER GASKET
|
|
PZ-7
|
4"
|
GM-1192-40HP
|
GM-25AT37
|
|
4-1/2"
|
GM-1192-44HP
|
|
5"
|
GM-1192-50HP
|
|
5-1/2"
|
GM-1192-54HP
|
|
6"
|
GM-1192-60HP
|
|
6-1/2"
|
GM-1192-64HP
|
|
6-3/4"
|
GM-1192-66HP
|
|
7"
|
GM-1192-70CR
|
|
PZ-8/9
|
4"
|
GM-1191-40HP
|
GM-25AT37
|
|
4-1/2"
|
GM-1191-44HP
|
|
5"
|
GM-1191-50HP
|
|
5-1/2"
|
GM-1191-54HP
|
|
6"
|
GM-1191-60HP
|
|
6-1/4"
|
GM-1191-62HP
|
|
6-1/2"
|
GM-1191-64HP
|
|
6-3/4"
|
GM-1191-66HP
|
|
7"
|
GM-1191-70CR
|
|
PZ-10/11
|
4"
|
GM-0197-40HP
|
GM-25AT37
|
|
4-1/2"
|
GM-0197-44HP
|
|
5"
|
GM-0197-50HP
|
|
5-1/2"
|
GM-0197-54HP
|
|
6"
|
GM-0197-60HP
|
|
6-1/2"
|
GM-0197-64HP
|
|
6-3/4"
|
GM-0197-66HP
|
|
7"
|
GM-0197-70HP
|
|
A850PT
A1100PT
|
4"
|
GM-0289-40HP
|
GM-G753
|
|
4-1/2"
|
GM-0289-44HP
|
GM-G754
|
|
5"
|
GM-0289-50HP
|
GM-G742
|
|
5-1/2"
|
GM-0289-54HP
|
GM-G743
|
|
6"
|
GM-0289-60HP
|
GM-G745
|
|
6-1/2"
|
GM-0289-64HP
|
GM-G746
|
|
7"
|
GM-0289-70HP
|
GM-G756
|
|
|
